Marine Mooring Ring

Mooring Rings are generally used as central joining points for mooring systems, connected by mooring shackles.

Nominal Chain Size(mm): 19mm-76mm

Ring Size：1.6d(Body dia.) x 8d(OD)

Surface: Black Tar/ H.D.Galvanized

Availability:

Quantity:



Inquire Add to Basket

Product Description

Mooring ring/Mooring Ring for Aquaculture mooring/Connection Ring/Aquaculture Mooring Ring

Mooring Rings are generally used as central joining points for mooring systems. It's forged. Mooring rings are used in mooring system, which has multi mooring legs. It's connected by shackles.

mooring rings

Nominal Chain Size (mm)	Diameter (d mm)	Overall Diameter (mm)	Weight per Piece	Breaking Load KN	Proof Load KN
19	30.4	152	2.18	211	150
25	40	200	4.96	372	285
32	51.2	256	10.39	583	417
40	64	320	20.31	896	640
50	80	400	39.67	1370	981
56	89.6	448	55.77	1710	1220
64	102.4	512	83.2	2190	1560
76	121.6	608	139.3	3010	2150

Product Photos:

aquaculture mooring plate

mooring delta plate

Application:

MOORING SYSTEM

mooring ring aquaculture mooring ring marine mooring ring fish farming chain accessaries round ring connection ring aquaculture connection ring mooring ring for aquaculture fish farming mooring ring circular ring
