INJECTION MOLD DOUBLE HOLES BRACKET:
Double holes HDPE bracket is manufactured by mould pressure injection machine, the min. thickness of its part is ≥20mm. Double hole bracket together with butt fusion welding 110mm-350mm upright pipe and 110mm- 350mm same diameter Tee consists of cage I frame. I-frame is evenly distributed along the perimeter of the cage frame, with a spacing of 1.5m-2m.
450MM BRACKET TEST DATA:
FISH CAGE SPECIFICATION:
| Circumference | Floating Pipe Dia. | Handrail Pipe Dia. | Upright Pipe and Tee Dia. | Bracket Hole Dia. | Distance of the Bracket |
| m | mm | mm | mm | mm | m |
| 40-60 | 250 | 125 | 125, 125/125 | 250 | 1.5-2 |
| 60-80 | 315 | 125 | 125, 125/125 | 315 | 1.5-2 |
| 60-80 | 315 | 125 | 140, 140/125 | 315 | 1.5-2 |
| 80-120 | 400 | 140 | 160, 160/140 | 400 | 1.5-2 |
| 100-140 | 450 | 140 | 160, 160/140 | 450 | 1.5-2 |
| 120-160 | 500 | 160 | 180, 180/160 | 500 | 1.5-2 |
Norway Type Double Holes Bracket Photos:
